技術參數:
頻率響應:10Hz - 20KHz / ±0.35dB
總諧波失真 + 噪聲:≤0.5% @ 8Ω1kHz
信噪比:>99dB
信道隔離度 (1KHz):>70dB
轉換速率:>30v/μs
阻尼系數:>3000 (8Ohm) 20Hz to 100Hz
輸入阻抗: 10K Ω balance/ 20K Ω unbalance
輸入連接:XLR Active balanced pin1 gnd/pin 2+/pin3-
輸出連接:4 Neutrik NL4 Sockets
保護:short-circuit, DC,overload, overheat,ultrasonic, RF, voltage peak limit,
PT4.7四通道功放
額定功率RMS:(8Ω/20ms ) 700W×4
(4Ω/20ms) 1150W×4
PT4.9四通道功放
額定功率RMS:(8Ω/20ms ) 900W×4
(4Ω/20ms) 1500W×4
PT4.11四通道功放
額定功率RMS:(8Ω/20ms ) 1100W×4
(4Ω/20ms) 1830W×4
PT4.13四通道功放
額定功率RMS:(8Ω/20ms ) 1300W×4
(4Ω/20ms) 2150W×4
PT4.16四通道功放
額定功率RMS:(8Ω/20ms ) 1600W×4
(4Ω/20ms) 2650W×4
